●  Filter flow : 80~1500m³/h

● System working pressure:0.25-2.5Mpa

● Pressure rating:1.0Mpa/1.6Mpa/2.5Mpa

● Working temperature range:0~65℃

● Filtering precision:50-3000micron

● Pressure loss:<0.01Mpa

● Inlet and outlet Connection: flange

● Backwash time:12~18 sec

● Water usage during backwash cycle:1%~3%of filtered water

● Control mode: DP control/PLC timing control/manual

● Cleaning mode: suction nozzle

● Rated operating voltage:3-ph,380v,220v,50Hz

● Installation method: horizontal
