Environmental & Water Treatment Solutions · Filtration & Water Treatment Solutions
Water Filter F200
SKU 204/206/208/210/212/214/216/218
Price on request
Environmental & Water Treatment Solutions · Filtration & Water Treatment Solutions
Water Filter F300
F300 series adopt hydraulic piston driven type, and their inlet-outlet range varies form 4”to 18”and their capacity range varies up to 1500m³/h.The filter adopts suction nozzle cleaning method with two-stage filtration.
Price on request
●Filter flow：80~1500 m³/h
●System working pressure：0.25-2.5Mpa
●Pressure rating：1.0Mpa/1.6Mpa/2.5Mpa
●Working temperature range：0~65℃
●Filtering precision：50-3000micron
●Pressure loss：<0.01Mpa
●Inlet and outlet Connection：flange
●Backwash time:12~18 sec
●Water usage during backwash cycle：1%~3%of filtered water
●Control mode：DP control/PLC timing control/manual
●Cleaning mode：suction nozzle
●Rated operating voltage：220v,50Hz
●Installation method：horizontal
