TECHNICAL PARAMETERS

● Filter flow:15-60m³/h

●System working pressure:0.25-2.5Mpa

●Pressure rating:1.0Mpa/1.6Mpa/2.5Mpa

●Working temperature range:0~65℃

● Filtering precision:50-3000micron

●Inlet and outlet Connection:flange

● Backwash time:10~15 sec

●Water usage during backwash cycle:1%~3%of filtered water

● Control mode:DP control/PLC timing control/manual control

●Cleaning mode:suction nozzle

● Rated operating voltage:220V,50Hz

●Installation mode:vertical
